2 Pin Feedthrough

Working Voltage:

Current Rating: 2.5A

Conductor Material:

1 1
Product Code: E6501060
Estimated Lead Time: Confirmed on Request

Product Description

2 Pin Feedthrough with 7.25/7.10mm Tube (Weld) termination. Rated for a working temperature of -196°C to 450°C and leak rate < 1 x 10¯⁹ mbar l s¯¹.

Technical References

Download spec sheet
View full details

General Specifications

Breakdown Voltage Pin To Pin 500V
Current Rating 2.5A
Insulating Material Alumina (96-98%)
Magnetic Yes
Multi Pin Type Feedthrough
No Of Pins 2
Termination Tube (Weld)
Termination Size 7.25/7.10mm
U H V Capability < 1 x 10¯⁹ mbar l s¯¹
Working Temperature -196°C to 450°C
