700V SMA Single Connector

Working Voltage: 700V

Current Rating: 1A

Conductor Material:

Skip to product information
1 of 1
Product Code: C5001130
Estimated Lead Time: Confirmed on Request

Product Description

700V Single Ended SMA connector with 9.60/9.40mm Tube (Weld) termination. Rated for a working temperature of -196°C to 450°C and leak rate < 1 x 10¯⁹ mbar l s¯¹.

Technical References

View full details

General Specifications

Air Side Plug C5009001
Configuration Single Ended
Connector Type SMA
Current Rating 1A
Feedthrough Quantity 1
Insulating Material Alumina (96-98%)
Magnetic Yes
Shielding Grounded
Termination Tube (Weld)
Termination Size 9.60/9.40mm
U H V Capability < 1 x 10¯⁹ mbar l s¯¹
Working Temperature -196°C to 450°C
Working Voltage 700V
