Single Thermocouple (-) Copper/Nickel

Working Voltage: -

Current Rating: -

Conductor Material: Constantan

1 1
Product Code: D1502015
Estimated Lead Time: Confirmed on Request

Product Description

Single thermocouple feedthrough with Constantan conductor and Plain terminations. 11.47/11.42mm Skirt (Weld) mounting. Rated for a working temperature of -196°C to 450°C and leak rate < 1 x 10¯⁹ mbar l s¯¹.

Technical References

Download spec sheet
View full details

General Specifications

Conductor Material Constantan
Feedthrough Style Single
Insulating Material Alumina (96-98%)
Magnetic Yes
Termination Skirt (Weld)
Termination Size 11.47/11.42mm
Thermocouple Termination Plain
U H V Capability < 1 x 10¯⁹ mbar l s¯¹
Working Temperature -196°C to 450°C
