Viewport UHV Rotatable (20mm)

Working Voltage:

Current Rating:

Conductor Material:

1 1
Product Code: G6004030
Estimated Lead Time: Confirmed on Request

Product Description

Sapphire Viewport 20mm diameter with 70mm Rotatable Insert termination. Rated for a working temperature of -196°C to 450°C and leak rate < 1 x 10¯⁹ mbar l s¯¹.

Technical References

Download spec sheet
View full details

General Specifications

Magnetic Yes
Termination Rotatable Insert
Termination Size 70mm
U H V Capability < 1 x 10¯⁹ mbar l s¯¹
Viewport Material Sapphire
View Diameter 20mm
Working Temperature -196°C to 450°C
